Legrand radiant 2097TRWRWCCD4 GFCI Duplex Receptacle, 125 V, 20 A, NEMA: NEMA 5-20R, Black

Legrand

Legrand radiant 2097TRWRWCCD4 GFCI Duplex Receptacle, 125 V, 20 A, NEMA: NEMA 5-20R, Black

$26.31$26.31
Legrand radiant 2097TRWRWCCD4 GFCI Duplex Receptacle, 125 V, 20 A, NEMA: NEMA 5-20R, Black
  • Color: Black
  • Current Rating: 20 A
  • Dimensions: 1.62 in W x 1.13 in D x 4.19 in H
  • Material: Nylon
  • Mounting Type: Wall
  • Model #: 2097TRWRWCCD4
  • UPC #: 785007135954
  • SKU: 0253088

Your shopping list will be used for pickup in-store

Key Features

  • Part of the radiant® collection
  • New external backwire pressure plates
  • New posted terminal screws for faster installation
  • Conducts an automatic test every 3 s ensuring it's always ready to protect and if the device fails the test, the trip indicator light (red LED) flashes to signal that the GFCI should be replaced
  • Equipped with proven SafeLock protection feature
  • Redesigned side wire cavity improves speed of side wire installation
  • Feed-thru wiring configuration allows GFCI to protect downstream receptacles
  • Prevents line-load reversal miswire, no power to the face or downstream receptacles if wired incorrectly

Item Specifications

ColorBlack
Current Rating20 A
Dimensions1.62 in W x 1.13 in D x 4.19 in H
MaterialNylon
Mounting TypeWall
Nema RatingNEMA 5-20R
TypeSelf-Test Specification-Grade
Voltage Rating125 V
Wire Size14 AWG
