Legrand radiant 2087WCCD4 GFCI Receptacle, 125 V, 20 A, NEMA: NEMA 5-20R, Back and Side Wiring, White

Legrand

Legrand radiant 2087WCCD4 GFCI Receptacle, 125 V, 20 A, NEMA: NEMA 5-20R, Back and Side Wiring, White

$33.07$33.07
Legrand radiant 2087WCCD4 GFCI Receptacle, 125 V, 20 A, NEMA: NEMA 5-20R, Back and Side Wiring, White
  • Color: White
  • Current Rating: 20 A
  • Dimensions: 1.73 in W x 1.03 in D x 4.2 in H
  • Grounding Type: Grounded
  • Material: Thermoplastic
  • Model #: 2087WCCD4
  • UPC #: 785007135817
  • SKU: 0254094

Your shopping list will be used for pickup in-store

Key Features

  • Part of the radiant collection of wiring devices, wallplates and home systems
  • Rated as a 1-1/2 hp motor control switch
  • Thinner than competitors' GFCI Receptacles leaves more room for wires in the box
  • Auto-ground clip assures a positive ground to metal box
  • Feed-thru wiring configuration allows GFCI to protect downstream receptacles
  • Prevents line-load reversal miswire, no power to the face or downstream receptacles if wired incorrectly
  • Trip indicator light
  • Two back wire holes per terminal
  • Ground screw has a back wire clamp for easy installation
  • Mounting screws are shipped captive in the device and wallplate for easier installation

Item Specifications

ColorWhite
Current Rating20 A
Dimensions1.73 in W x 1.03 in D x 4.2 in H
Grounding TypeGrounded
MaterialThermoplastic
Mounting TypeScrew
Nema RatingNEMA 5-20R
Number Of Wires3
Short Circuit Current Rating10 kA
Voltage Rating125 V
Wire Size14 to 10 AWG
Wiring TypeBack and Side
